4 Core Gyfxtby Outdoor Flat Fiber Optic Cable

Name: 4 Core Gyfxtby Outdoor Flat Fiber Optic Cable
Brand: guangzhou fiber cablepuls co ltd
SKU: GYFXTBY-4b1.3
Availability: InStock

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	PUNAISGD
Certification:	CE/ROHS/ISO9001
Model Number:	GYFXTBY-4b1.3

Detail Information

Place of Origin:

Guangdong, China

Brand Name:

PUNAISGD

Certification:

CE/ROHS/ISO9001

Model Number:

GYFXTBY-4b1.3

Type:

GYFXTBY-4b1.3

Cores:

4 Fibers

Strength Member Material:

FRP

Construction:

Central Loose Tube

Useful:

Outdoor Fiber Optic Cable

Transport Package:

Wooden Drum

Cable Dimension:

6.5mm

Jacket Color:

Black

Mode:

Singlemode G652D

Name:

Outdoor Fiber Optic Cable

Highlight:

High Light

Highlight:

4 core outdoor fiber optic cable

4 core outdoor armored fiber optic cable

g652d outdoor fiber optic cable

Trading Information

Minimum Order Quantity:

1km

Price:

negociate

Packaging Details:

woode drum

Delivery Time:

7days

Payment Terms:

T/T,Western Union

Supply Ability:

1000000km/month

Product Description

4 Core Gyfxtby Outdoor Flat Fiber Optic Cable

Product Attributes

Attribute	Value
Type	GYFXTBY-4b1.3
Cores	4 fibers
Strength Member Material	FRP
Construction	Central Loose Tube
Useful	Outdoor Fiber Optic Cable
Transport Package	Wooden Drum
Cable Dimension	6.5mm
Jacket Color	Black
Mode	Singlemode G652D
Name	Outdoor Fiber Optic Cable

Product Description

General

This specification covers the design requirements of structure, mechanical, physical and performance standards for the supply of optical fiber cables. The features described in this document are intended to provide information on the performance of optical cable.

Specifications

General Specifications

Cable Type	4 Core GYFXTBY Outdoor Flat Fiber Optic Cable
Fiber Type	SM G657A1/ SM G657A2
Application	FTTH, LAN
Recommended installation methods	Aerial
Environment	Indoor
Temperature Range	-40ºC to 70ºC

Fiber Specifications

Fiber style	Unit	SM
Fiber style	Unit	G652D	G657A1	G657A2
condition	nm	1310/1550	1310/1550	1310/1550
condition	dB/km	≤0.36/0.23	≤0.35/0.21	≤0.35/0.21

Standard Color Identification of Fiber

No. 1

Blue

No. 2

Orange

No. 3

Green

No. 4

Brown

Strength Member

The strength member is made of Aramid yarns. It provides tensile to the cable. Sheath protects cable from water intrusion.

Outer Jacket

PE sheath is extruded over the fiber.

Cable Sheath Marking

Each cable have the following information clearly marked on the outer jacket of cables:

Name of manufacturer
Year of manufacturer
Type of cable and fiber
Length mark (printing on each meter normally)
Or as customer's requirements
