ADSS Fiber Optic Cable Aerial Self Supported ASU Fiber Optic Cable

Name: ADSS Fiber Optic Cable Aerial Self Supported ASU Fiber Optic Cable
Brand: guangzhou fiber cablepuls co ltd
SKU: ASU-16B1.3
Availability: InStock

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	PUNAISGD
Certification:	CE/ROHS/ISO9001
Model Number:	ASU-16B1.3

Detail Information

Place of Origin:

Guangdong, China

Brand Name:

PUNAISGD

Certification:

CE/ROHS/ISO9001

Model Number:

ASU-16B1.3

Type:

ASU-16B1.3

Application:

Telecom Comunication

Strength Member:

Frp *2pcs

Jacket Color:

Black Color/Others

Span:

80 120

Warranty Period:

25 Years

Istallation:

Aerial

Laying Mode:

Aerial

Filler:

Filling Compound

Name:

ADSS Fiber Optic Cable

Highlight:

High Light

Highlight:

black adss fiber optic cable

black adss optic fiber cable

Trading Information

Minimum Order Quantity:

1km

Price:

negociate

Packaging Details:

wooden drum

Delivery Time:

7days

Payment Terms:

T/T,Western Union

Supply Ability:

100000

Product Description

ADSS Fiber Optic Cable Aerial Self Supported ASU Fiber Optic Cable

The ASU 6-core 120m span design offers an affordable alternative for fiber to the home (FTTH) projects as an access approach cable. Featuring two FRP strength members for excellent mechanical performance and a single loose tube design for lighter weight and easier installation, this cable is increasingly popular among ISP companies. The HDPE outer sheath provides superior UV resistance, ensuring durability even with prolonged sun exposure.

Type	ASU-16B1.3
Application	Telecom Communication
Strength member	FRP *2pcs
Jacket color	Black Color/Others
Span	80-120
Warranty Period	25 years
Installation	Aerial
Laying Mode	Aerial
Filler	Filling Compound

PRODUCT SPECIFICATIONS

ITEMS	UNITS	SPECIFICATION
Fiber Type		G652D
Attenuation	dB/km	Before Cable: 1310nm ≤ 0.34, 1550nm ≤ 0.21 After Cable: 1310nm ≤ 0.35, 1550nm ≤ 0.22
Attenuation	Chromatic Dispersion	ps/nm.km: 1310nm ≤ 3.5, 1550nm ≤ 18, 1625nm ≤ 22
Attenuation Uniformity	dB/km	0.1
Point Discontinuities	dB	≤ 0.05
Zero Dispersion Slope	ps/n㎡.km	0.093
Zero Dispersion Wavelength	nm	1300~1324
PMDQ Link Design 1550	ps/km1/2	≤ 0.1
Cut-off Wavelength(λcc)	nm	≤ 1260
Attenuation vs. Bending(60mm*100turns)	dB	≤ 0.1 at 1625 nm(60mm * 100turns)
Mold Field Diameter	μm	9.2±0.4 @ 1310nm 10.4±0.5@ 1550nm
Core-Clad Concentricity	μm	≤ 0.6
Cladding Diameter	μm	125 ± 1
Cladding Non-circularity	%	≤ 1
Coating Diameter	μm	245 ± 5
Proof Test	Gpa	≥ 0.69

Optical Characteristics

Parameter	6 Fiber	8 Fiber	12 Fiber	24 Fiber
Part code	ASU-120-6F
Number of Fibers	6	8	12	24
Number of fiber in tube	6	8	12	24
Number of loose tube	1	1	1	1
Strength member	FRP 2×2.2mm	FRP 2×2.2mm	FRP 2×2.2mm	FRP 2×2.3mm
Loose tube material	PBT
Loose tube size	2.2mm
Outer sheath material	HDPE
Cable nominal diameter	7.2 ±0.2mm	7.2 ±0.2mm	7.2 ±0.2mm	8.0 ±0.2mm
Cable nominal weight	45 ±5 kg/km	45 ±5 kg/km	45 ±5 kg/km	47 ±5 kg/km
Max. working tension	1500 N
Max. crush resistance	1000 N (Short term) / 600 N (Long term)
Min. bending radius	20× cable OD at full load 15× cable OD at no load
Temperature range	Installation: -0°C to +50°C Operation: -10°C to +70°C
