Lightweight ADSS Fiber Optic Cable Single Jacket All Dielectric Self Supporting Cable

Name: Lightweight ADSS Fiber Optic Cable Single Jacket All Dielectric Self Supporting Cable
Brand: guangzhou fiber cablepuls co ltd
SKU: ADSS-60B1.3
Availability: InStock

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	PUNAISGD
Certification:	CE/ROHS/ISO9001
Model Number:	ADSS-60B1.3

Detail Information

Place of Origin:

Guangdong, China

Brand Name:

PUNAISGD

Certification:

CE/ROHS/ISO9001

Model Number:

ADSS-60B1.3

Name:

ADSS Fiber Optic Cable

Type:

ADSS-60B1.3

Model No:

All Dielectric Cable

Strength Member:

Aramid Yarn

Cable Model:

Double Jacket/single Jacket

Package:

Wooden Drum/Customized

Cable Weight:

200 Kg/km

Installation Method:

Aerial

Life Expectancy:

30 Years

Fiber Type:

Single-mode G.652D

Outer Diameter:

10.5mm

Highlight:

High Light

Highlight:

Lightweight ADSS Fiber Optic Cable

ADSS Fiber Optic Cable Single Jacket

All Dielectric Self Supporting Cable

Trading Information

Minimum Order Quantity:

1km

Price:

negociate

Packaging Details:

wooden drum

Delivery Time:

7days

Payment Terms:

T/T,Western Union

Supply Ability:

100000

Product Description

Lightweight ADSS Fiber Optic Cable Single Jacket All Dielectric Self Supporting Cable

Product Attributes

Attribute	Value
Name	ADSS Fiber Optic Cable
Type	ADSS-60B1.3
Model No	All Dielectric Cable
Strength Member	Aramid Yarn
Cable Model	Double Jacket/single jacket
Package	Wooden Drum/Customized
Cable Weight	200 kg/km
Installation Method	Aerial
Life Expectancy	30 Years
Fiber Type	Single-mode G.652D
Outer Diameter	10.5mm

Product Description

ADSS Fiber Optic Cable Single Jacket All Dielectric Self-Supporting Cable

The structure of ADSS (single-sheath stranded type) is to place 250um optical fiber into a loose tube made of PBT, which is then filled with waterproof compound. The center of the cable core is a non-metallic central reinforcement made of fiber-reinforced composite (FRP). The loose tubes (and filler rope) are twisted around the central reinforcing core. The seam barrier in the relay core is filled with water-blocking filler, and a layer of waterproof tape is extruded outside the cable core. Rayon yarn is then used, followed by extruded polyethylene (PE) sheath into the cable. It is covered with a thin polyethylene (PE) inner sheath. After a stranded layer of aramid yarns is applied over the inner sheath as a strength member, the cable is completed with a PE or AT (anti-tracking) outer sheath.

Product Features

Can be installed without shutting off the power.
Resistant to high and low temperature cycles, resulting in anti-aging and a longer lifespan.
Lightweight and small diameter reduce the load caused by ice and wind, as well as the load on towers and backprops.
Large span lengths and the longest span is over 1000m.
Good performance in tensile strength and temperature.
Large number of fiber cores, lightweight, can be laid with the power line, saving resources.
Adopt high-tensile-strength aramid material to withstand strong tension and prevent wrinkles and punctures.
The design lifespan is over 30 years.

Product Specifications

Dimensions of Cable Constructions

Fiber count	Structure	Fibers per tube	Loose tube diameter (mm)	CSM diameter/pad diameter (mm)	Nominal Thickness of outer jacket (mm)	Cable diameter/ Height (mm)	Cable weight (kg/km)
4	1+6	4	1.9±0.1	2.0/2.0	1.6	9.5±0.2	80
6	1+6	6	2.0±0.1	2.0/2.0	1.6	9.8±0.3	80
8	1+6	4	1.9±0.1	2.0/2.0	1.6	9.8±0.3	80
12	1+6	6	2.1±0.1	2.0/2.0	1.6	9.8±0.3	80
24	1+6	12	2.1±0.1	2.0/2.0	1.6	9.8±0.3	80
36	1+6	12	2.2±0.1	2.0/2.0	1.6	10.0±0.3	85
