Armored Outdoor Fiber Optic Cable Multimode 12/8/4 Core GYXTW OM2 Fiber Optic Cable

Name: Armored Outdoor Fiber Optic Cable Multimode 12/8/4 Core GYXTW OM2 Fiber Optic Cable
Brand: guangzhou fiber cablepuls co ltd
SKU: GYXTW-2B1.3
Availability: InStock

Product Details:

Place of Origin:	china
Brand Name:	PUNAISGD
Certification:	CE/ROHS/ISO9001
Model Number:	GYXTW-2B1.3

Detail Information

Place of Origin:

china

Brand Name:

PUNAISGD

Certification:

CE/ROHS/ISO9001

Model Number:

GYXTW-2B1.3

Name:

Armored Outdoor Fiber Optic Cable

Type:

GYXTW-2B1.3

Strength Member:

Two Steel Wire

Fiber Type:

OM2

Central Strength Member:

Steel Wire

Installation:

Aerial

Business Type:

Manufacturer

Oem:

YES

Laying Methods:

Aerial

Construction:

Stranded Loose Tube

Armour:

Steel Tape

Highlight:

High Light

Highlight:

Armored Outdoor Fiber Optic Cable

Outdoor Multimode Fiber Optic Cable GYXTW

OM2 Fiber Optic Cable Armored

Trading Information

Minimum Order Quantity:

1km

Price:

negociate

Packaging Details:

woode drum

Delivery Time:

7days

Payment Terms:

T/T,Western Union

Supply Ability:

1000000km/month

Product Description

Armored Outdoor Fiber Optic Cable Multimode 12/8/4 Core GYXTW OM2 Fiber Optic Cable

Product Attributes

Attribute	Value
Name	Armored Outdoor Fiber Optic Cable
Type	GYXTW-2B1.3
Strength Member	Two steel wire
Fiber Type	OM2
Central Strength Member	Steel Wire
Installation	Aerial
Business Type	Manufacturer
Oem	YES
Laying Methods	Aerial
Construction	Stranded Loose Tube
Armour	Steel Tape

Product Description

The fibers, 200/250um, are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. The tube is wrapped with a layer of PSP longitudinally. Between the PSP and the loose tube water-blocking material is applied to keep the cable compact and watertight. Two parallel steel wires are placed at the two sides of the steel tape. The cable is completed with a polyethylene (PE) sheath.

Product Features

Good mechanical and temperature performance
High strength loose tube that is hydrolysis resistant
Special tube filling compound ensure a critical protection of fiber
Crush resistance and flexibility
PSP enhancing moisture-proof
Two parallel steel wires ensure tensile strength
PE sheath gives excellent UV protection
Small diameter, light weight and friendly installation
Long delivery length

Technical Specifications

Product Name	GYXTW fiber optic cable
Fiber Count	8 Fibers
Construction	Central Loose Tube
Fiber Type	Singlemode 9/125
Outer Jacket Material	PE(Black)
Strength Member Material	Steel Wire
Weight	50KG/KM
Armor Layer	PSP Steel
Application	Aerial and Duct
Steel Diameter	0.8mm *2
Jacket Diameter	8.0mm-10.0mm
Jacket Material	PE
Test Wavelength	1310/1550nm
Operation temperature	-40℃~ 85℃
