PE HDPE SM MM Outdoor Fiber Optic Cable Single Mode 24 Cores 60 Span

Name: PE HDPE SM MM Outdoor Fiber Optic Cable Single Mode 24 Cores 60 Span
Brand: guangzhou fiber cablepuls co ltd
SKU: ADSS-24B1.3-60m
Availability: InStock

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	PUNAISGD
Certification:	CE/ROHS/ISO9001
Model Number:	ADSS-24B1.3-60m

Detail Information

Place of Origin:

Guangdong, China

Brand Name:

PUNAISGD

Certification:

CE/ROHS/ISO9001

Model Number:

ADSS-24B1.3-60m

Name:

Outdoor Fiber Optic Cable

Type:

ADSS-24B1.3-60m

Application:

Telecom Comunication

Strength Member:

Kevlar

Jacket Color:

Black Color

Packing:

Wooden Drum

Number Of Conductors:

24 Cores

Fiber Type:

G652D

Outer Sheath:

PE/AT,AT/PE,PE

Span:

Highlight:

High Light

Highlight:

MM Outdoor Fiber Optic Cable

Outdoor Fiber Optic Cable Single Mode

HDPE Fiber Optic Cable Outdoor

Trading Information

Minimum Order Quantity:

1km

Price:

negociate

Packaging Details:

wooden drum

Delivery Time:

7days

Payment Terms:

T/T,Western Union

Supply Ability:

100000

Product Description

ADSS Customizable Factory Direct Sales PE HDPE Single Mode SM MM Outdoor Fiber Optic Cable

Product Specifications

Attribute	Value
Type	ADSS-24B1.3-60m
Application	Telecom Communication
Strength member	Kevlar
Jacket color	Black
Packing	Wooden drum
Number of conductors	24 cores
Fiber type	G652D
Outer sheath	PE/AT, AT/PE, PE
Span	60

Product Description

All Dielectric Self Supporting cable (ADSS) is a type of fiber optic cable designed for aerial applications. This innovative cable doesn't require a messenger for support, enabling single-pass installation.

What is ADSS All Dielectric Self Supported Optical Cable?

The Aramid Yarn G652D ADSS Communication Fiber Optic Cable features a loose-jacketed stranded structure. Single-mode or multimode optical fibers are housed in high-modulus plastic loose tubes filled with water-repellent compound. These tubes are twisted around a central FRP reinforcement to form a compact cable core, with aramid fiber reinforcement and PE or electric trace-resistant outer sheath.

ADSS Cable Types

Single sheath: FRP + Aramid yarn + Outer sheath
Double sheath: FRP + Inner sheath + Aramid yarn + Outer sheath

Optical Characteristics

Item	Contents	Value
Item	Contents	24	48	72	96	144
Fiber Count		24	48	72	96	144
Loose Tube	No. of tubes*fiber per tube	4*6	4*12	6*12	8*12	12*12
Outer Diameter(mm)		2.1	2.5

Item	G.652	G.655	50/125um	62.5/125um
Attenuation @850nm			≤3.0dB/km	≤3.2dB/km
Attenuation @1300nm			≤1.0dB/km	≤1.2dB/km
Attenuation @1310nm	≤0.36dB/km	≤0.40dB/km
Attenuation @1550nm	≤0.22dB/km	≤0.23dB/km
Bandwidth @850nm			≥500MHZ.km	≥200MHZ.km
Bandwidth @1300nm			≥1000MHZ.km	≥600MHZ.km
Numerical aperture			0.200±0.015NA	0.275±0.015NA
Cable cut-off wavelength	≤1260mm	≤1450mm

Our Factory

Frequently Asked Questions

1. Why choose us?

We are a manufacturer located in Guangzhou, China, operating since 2011. Our factory employs 11-50 people and serves domestic markets.

2. How can we guarantee quality?

We provide pre-production samples before mass production and conduct final inspections before shipment.

3. Can you send products to my country?

Yes, we can. If you don't have your own shipping forwarder, we can assist with logistics.

4. Can you do OEM for me?

We accept all OEM orders. Contact us with your design for a competitive quote and sample production.

5. What services can we provide?

Delivery Terms: FOB, CIF, EXW
Payment Currency: USD, EUR, JPY, CAD, AUD, HKD, GBP, CNY, CHF
Payment Type: T/T, L/C, D/P D/A, PayPal, Western Union, Escrow
Languages: English, Chinese
