| Place of Origin: | China |
|---|---|
| Brand Name: | Yiyuan |
| Certification: | OHSAS 18001, ISO 14001, ISO 9001 |
| Minimum Order Quantity: | 1KM |
| Price: | Negotiation |
| Packaging Details: | Wood coil strand |
| Delivery Time: | 30 working days after received your payment |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 500000km/month |
| Product Name: | Non Metallic Fiber Optic Cable | Number Of Cores: | 2-144 Core |
|---|---|---|---|
| Outer Sheath Material: | PE | OEM: | Accepted |
| Application: | Outdoor Duct/outdoor Cable/aerial/lashed | Brand Name: | Yiyuan |
| Certification: | ISO 9001;ISO 14001;OHSAS 18001 | Color: | Black Or Customized |
| Number Of Conductors: | ≥ 10 | Place Of Origin: | China |
| Installation: | Self-supporting Aerial | Package: | Plywood Reel/customized |
| Fiber Type: | Single Mode | Strength Member: | FRP |
| High Light: | G.655 48 pair fiber optic cable,48 pair fiber optic cable 1450 nm |
||
Duct Aerial Armored 48 Pair Fiber Optic Cable Aluminum Tape Metallic Strength Member
Quick Description
GYTA is one of our outdoor fiber optic cable with aluminum armored sheath and metallic strength member inside. Its a type of fiber optic cable in stranded loose tube with compact structure and the cable jacket is made of strong polyethylene.
High strength loose tube has hydrolysis resistant. Cable filling materials ensure high reliability, and APL makes the cable crush resistant and moisture proof. So, the GYTA has a very good watertight performance. This cable can be used for LAN and WAN backbones, telecom access lines, fibre to business and fibre to the building drop connections, as well as fibre to the home drop and access connections.
Features
1. Good mechanical and temperature performance.
2. High strength loose tube that is hydrolysis resistant.
3. Special tube filling compound ensure a critical protection of fiber.
4. Crush resistance and flexibility.
5. Small diameter, light weight and friendly installation.
Application
CATV
Local trunk line
Rural communication
Computer networks system
Aerial & conduit/duct application
Optical Characteristics
| G.652 | G.655 | 50/125 µm | 62.5/125 µm | ||
| Attenuation(+20℃) | @ 850 nm | ≤ 3.0 dB/km | ≤ 3.0 dB/km | ||
| @1300 nm | ≤ 1.0 dB/km | ≤ 1.0 dB/km | |||
| @1310 nm | ≤ 0.36 dB/km | ≤ 0.40 dB/km | |||
| @1550 nm | ≤ 0.22 dB/km | ≤ 0.23 dB/km | |||
| Bandwidth(Class A) | @ 850 nm | ≥ 500 MHz·km | ≥ 200 MHz·km | ||
| @1300 nm | ≥ 1000 MHz·km | ≥ 600 MHz·km | |||
| Numerical Aperture | 0.200 ± 0.015 NA | 0.275 ± 0.015 NA | |||
| Cable Cut-off Wavelength lcc | ≤ 1260 nm | ≤ 1450 nm | |||
