| Place of Origin: | China |
|---|---|
| Brand Name: | Yiyuan |
| Certification: | OHSAS 18001, ISO 14001, ISO 9001 |
| Minimum Order Quantity: | 1KM |
| Price: | Negotiation |
| Packaging Details: | Wood coil strand |
| Delivery Time: | 30 working days after received your payment |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 500000km/month |
| Product Name: | Non Metallic Fiber Optic Cable | Number Of Cores: | 2-144 Core |
|---|---|---|---|
| Outer Sheath Material: | PE | Application: | Outdoor Duct/outdoor Cable/aerial/lashed |
| Brand Name: | Yiyuan | Certification: | ISO 9001;ISO 14001;OHSAS 18001 |
| Color: | Black Or Customized | Place Of Origin: | China |
| Installation: | Self-supporting Aerial | Package: | Plywood Reel/customized |
| Strength Member: | FRP | ||
| High Light: | 20D ADSS Fiber Optic Cable,1000N ADSS Fiber Optic Cable,2 core outdoor cable 8.5mm |
||
2 Core Outdoor ADSS Fiber Optic Cable Waterproof Splice Enclosure For Telecommunication
Descriptions:
GYXTW fiber optic cable is a type of fiber cable that is widely used in aerial application. This type of fiber cable has been praised due to its exceptional performance in Long Distance Symmetric role. As a matter of fact, GYXTW fiber optic cable plays an important role in the telecommunication industry and it’s highly recommended by many technicians.
Characteristics:
Structure with central tube, parallel steel wire, corrugated steel tape armoring;
Small diameter, lighter, easy installation.
Loose tube material has good hydrolysis resistance performance and high strength;
Excellent moisture, water-blocking perfomance;
Glass yarn strength member improve the mechanical properties, and can also prevent ant bites.
Good mechanical performance and environmental properties.
Applications:
Duct, aerial
Access network, FTTH
Temperature:
Operating temperature: -40°C~+70°C
Technical Parameter
| Fiber Count | Diameter(mm) | Weight (kg/km) | Tensile(N) | Crush(N) | Bending Radius(mm) | |||
| 2~12 | 8.5 | 75 | Long term | Short term | Long term | Short term | Static | Dynamic |
| 600 | 1500 | 300 | 1000 | 10D | 20D | |||
| 2~12 | 9.1 | 100 | 1000 | 3000 | 1000 | 300 | 10D | 20D |
| 24 | 9.5 | 110 | 600 | 1500 | 300 | 1000 | 10D | 20D |
